FH4-2 Fiber Marking Machine Handheld

Short Description:

The service life of the hand-held laser marking machine is up to 100,000 hours. The service life of the machine is long, and the customer does not need to replace the machine frequently, so that the customer can save a lot of cost when using the laser marking machine for marking and obtain the maximum benefit with the minimum cost.

The hand-held laser marking machine is maintenance-free. The maintenance of the machine is one of the ways to make the machine work better, and the maintenance-free feature saves customers a lot of unnecessary trouble, saves time, and indirectly improves work efficiency.

The marking characters are clear and precise, and the energy consumption is low. The portable laser marking machine acts on the material, and the processed product pattern image is vivid and clear, which is easy to be accepted by the market.

It has the advantages of easy portability, good flexibility, environmental protection and energy saving. Customers can process products at home or in places with relatively small space, which provides convenience for customers.

Send email to us Download To PDF

Detail

Specifications
Model	FH
Laser Power	20W-100W
Laser Wavelength	1064nm
Q-frequency	20KHZ-100KHZ
PMW	0-20 Adjustable
Divergence	0.3mard
Marking Range	110110mm/150150mm/175175mm/200200mm/300*300mm(optional)
Minimum Character	0.5mm
Minimum Line Width	0.01mm
Minimum Depth	0-1mm(Depending on the materials)
Engraving Line Speed	≤7000mm/s
Scope of Marking	All metals and some non-metals (such as hard plastics)
Consumables	No consumables
Marking thickness	depends on different materials and is related to the hardness of the materials
Laser head and service life	Theoretical lifespan 100000 hours
Warranty period	One year warranty for the entire machine, two years warranty for the laser
Working Size	default 110 * 100mm, can be selected according to needs
Repeatability Accuracy	±0.001mm
Beam Quality	M2:1.2-1.8
Marking Format	Graphics,text,bar codes,two-dimension code,automatically marking the date, batch number,serial number, frequency,etc
Graphic Format Supported	BMP,JPG,GIF,PNG,TIF,AI,DXF,DST,PLT,etc.
Working Voltage	220V/50HZ/4A
Unit Power	<0.5kw
Working Environment Required	Clean and dust free or dust less
Working Condition	humidity 5%-95%,Free of condensed water
Laser Module Life	Around 100000 hours
Laser Source	MAX/RAYCUS/JPT
Control Card	JCZ Brand EZCAD

Product Description:

Handheld fiber laser marking machines are highly efficient and energy-saving in practical applications, with meager operating costs due to the absence of consumables. Additionally, the marking process does not produce any polluting gases, thus having no negative impact on the environment. As handheld laser marking machines become more widespread and market demand increases, their prices become more affordable, making them accessible to a broader range of businesses.

Currently, handheld laser marking machines have found extensive applications in industries such as mechanical manufacturing, packaging, and consumer DIY. They help businesses achieve higher production efficiency while ensuring product quality. With further power increases, handheld fiber laser marking machines are expected to gain broader applications in emerging markets, such as handheld engraving and marking.

Application of mini fiber laser marking machine

Suitable for all kinds of metal materials and some non-metal materials marking, engraving. Large machinery parts, automobile and mechanical parts, hardware tools, instruments and meters, aerospace and aviation components; Electronic and communication products, integrated circuit chips, computer accessories and electrical appliances;

Jewelry, clocks and watches, gifts, office supplies, trademarks, sanitary ware; Tableware, food, beverage, tobacco and alcohol and other areas of graphic and text marking, as well as mass production line operations.
